Gigabyte H610M H DDR5 Intel 12th/13th/14th Gen Micro-ATX Motherboard

Gigabyte H610M H DDR5 Intel 12th/13th/14th Gen Micro-ATX Motherboard

Status: In Stock
Brand: Gigabyte
Model: Gigabyte H610M H DDR5

Based on 0 reviews. - Write a review

10,500৳

Ex Tax: 10,500৳

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে |

Key Features

Chipset: Intel H610
Supported CPU: Intel Core 14th, 13th & 12th Gen (LGA1700)
Memory: 2x DDR5 DIMM Slots, Up to 96GB
Display: HDMI & D-Sub (VGA) Ports
Storage: 1 x M.2 PCIe 3.0 x4 Slot

Chat Through

Messenger

Basic Information
Supported CPU	Socket: LGA1700 Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors* L3 cache varies with CPU * Please refer to "CPU Support List" for more information.
Chipset	Intel® H610 Express Chipset
Generation	12th/13th/14th
Form Factor	Micro ATX Form Factor; 23.0cm x 21.5cm
Audio	Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Expansion Slots
M.2 Socket	Yes
PCI	CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Graphics Information
Graphics	Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz Support for HDMI 2.1 version and HDCP 2.3. Support native HDMI 2.1 TMDS compatible ports (Graphics specifications may vary depending on CPU support.)
Max Shared Graphics	128GB
Memory Information
Memory Type	14th and 13th Generation Intel® Core™ i9/i7 Processors: Support for DDR5 5600/5200/4800/4400 MT/s memory modules 13th Generation Intel® Core™ i5/i3 and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors: Support for DDR5 4800/4400 MT/s memory modules 2 x DDR DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
Slots	2
Maximum Memory	up to 64 GB (32 GB single DIMM capacity) of system memory
Connector & Ports
VGA	Yes
HDMI	Yes
Display Port	Yes
LAN Port (s)	Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Supported Storage	Chipset: 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors
USB (s)	Chipset: 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports on the back panel Chipset+USB 2.0 Hub: 4 x USB 2.0/1.1 ports available through the internal USB headers
Manufacturer Warranty
Warranty Details	03 Years Brand Warranty

Reliable Foundation for Intel Core Processors The Gigabyte H610M H DDR5 is a high-quality Micro-ATX motherboard designed to support Intel Core 14th, 13th, and 12th Generation processors. Built on the Intel H610 chipset, it offers a perfect balance of performance and value for home and office computing.

Key Performance Features:

DDR5 Memory Support: Features dual-channel DDR5 slots, providing higher bandwidth and improved system efficiency compared to previous generations.
Stable Power Delivery: Equipped with a 6+1+1 phases hybrid digital VRM design to ensure clean and efficient power to the CPU.
High-Speed Storage: Includes a PCIe 3.0 x4 M.2 slot for fast NVMe SSD performance, significantly reducing boot and load times.
Advanced Cooling: Features Smart Fan 6 technology with multiple temperature sensors and hybrid fan headers for quiet and effective thermal management.
Connectivity: Offers a smooth networking experience with Intel GbE LAN and bandwidth management, along with high-quality audio capacitors for immersive sound.
